 This heavy duty pump is ideal for charging oil in or adding oil to large systems.
With a 1/2 H.P. electric motor directly coupled to a fixed-displacement gear pump, oil can be pumped intp the system even while in operation.
This pump could also be used for any oil transfer. It is capable of pumping the contents of a 45-gal drum to your system in less than 20 min.
A ball-type chack valve is installed at the pump outlet to prevent oil or refrigerant from flowing back in case of a power failure or breakdown.
Spécifications
| Flow ratings: |
2.9 us G.P.M. 1725 R.P.M. |
| Pressure ratings: |
270 p.s.i. using 0.5 h.p. (1/2 h.p.) |
| Max. pressure: |
3500 p.s.i. |
| Motor: |
0.5 h.p. (1/2 h.p.) T.E.F.C. capacitor start thermal over load protected |
|
Flexible waterproof cover on reset button ans on/off toggle switch
Five ft power cord
C.S.A. approved |
| Voltage: |
Dual voltage 115/230 60 Hz |
| R.P.M.: |
1725 |
| Suction hose: |
1/2 in I.D. x 6 ft Vinyl hose c/w |
|
Quick disconnect coupling |
| Discharge hose: |
3/8 in I.D. x 8 ft |
|
Safe hydraulic hose max. pressure 3000 p.s.i. |
| Weight: |
34 lbs |
| Size: |
L: 18.5 in |
|
W: 8.5 in |
|
H: 13 in |
 |
